Description:
Dimensions
Length: 15.5′
Height: 11’ 8”
Width: 4.5′
Weather Resistant Powder Coated Chassis
60″ Extended A-Frame Tongue
A – Frame Mounted Generator Tray
(2) 6,000 lbs Torsion Axle with electric brakes
(4) Aluminum Wheels with Goodyear Endurance Tires
Spare Tire on a Steel Wheel
Full Steel Skeleton Frame
Walls – Coated Fiberglass
Roof – One Piece EPDM / PVC Hybrid Roof Aluminum Trim & Corner Caps
(4) Exterior LED Overhead Lights
Diamond Plated Steel Stone Guard
Diamond Plated Steel Platform
Quartz Counter Tops
Vinyl Flooring – Color Options Available Water Resistant Paneling
LED Lights
(4) Roof Vent with Maxxair Cover
Shore Power: (2) 30 AMP
Water: Tank Fill
Solar Power Kit with Battery Tender
(2) 30 AMP Breaker Box with (1) 30 AMP Converter
12v Fuse Panel
(1) 12v Battery with Battery Disconnect Switch
(1) Roof Top A/C (15,000 BTU Cooling & 12,000 BTU Heating)
(4) Porcelain Sink – Vessel Bowl
(4) Delta Faucet with Lifetime Warranty
(4) Touchscreen LED Backlit Mirror. (4) Porcelain Toilet – Dometic Series 510
(2) Point of Use Water Heater
(2) 3 Gallon per Minute Water Pumps – For Redundancy
Brass Fittings
Pex Pipe Plumbing
Water Shutoff Valve – On All Fixtures
Pump Assisted Draining Valve Location for Draining Fresh Water Tank
12v Battery Disconnect Switch
Timed Light Mec. Room Light Switch
Fresh Water & Wasted Tank Capacity Monitor
2 – Way Pump Switch with Heater Control
Thermostat
Fuse Panel
Breaker Box
Solar Panel Converter
Quick Access Cover For Wiring
Labeled Wiring Behind the Quick Access Cover
Fresh Water Tank – (1) 160 Gallon with Overflow Valve and Pump Assisted Draining
Waste Tank – (1) 375 Gallon Welded Co-Poly Tank
Industrial Dump Valve
